엡손 WF-2850, 2851 그리고 2855 에 대한 에러코드 입니다.
번역을 하다 포기 했습니다.
머리로 이해되는걸 글로 표현해서 의미를 전달하기가 참 어렵군요.. ㅠㅠ
에러 뜰 경우, 검색해서 참고하시기 바랍니다. ^^
| 에러 코드 | 구분 | 에러 내용 |
| 0x0000 | GENERAL | Fatal error does not occur. |
| 0x0002 | GENERAL | Unrecoverable firmware bug. |
| 0x0A3C | GENERAL | Board Failure (Wi-Fi). |
| 0x0A3F | GENERAL | Board Failure (NFC). |
| 0x0BBA | GENERAL | Panel Failure (TOUCH). |
| 0x0BBC | GENERAL | Panel Failure (UNIT). |
| 0x0C81 | GENERAL | Board Failure (PDL). |
| 0x13EE | GENERAL | Board Failure (CARD). |
| 0x0000 | PRINTER | Fatal error does not occur. |
| 0x0014 | PRINTER | CR PID driving time error. Main board failure. |
| 0x0015 | PRINTER | CR PID excess load error. CR encoder failure. CR motor failure. CR Mechanism overload. Tooth skip or improper tension of the timing belt. Cable or FFC disconnection. Motor driver failure. Main board failure. |
| 0x0016 | PRINTER | CR PID excess speed error. CR encoder failure. Tooth skip or improper tension of the timing belt. Cable or FFC disconnection. Motor driver failure. Main board failure. |
| 0x0017 | PRINTER | CR PID reverse error. CR encoder failure. External force or vibration. Tooth skip or improper tension of the timing belt. Paper jam. Motor driver failure. Main board failure. |
| 0x0018 | PRINTER | CR PID lock error. CR encoder failure. CR motor failure. CR Mechanism overload. Some part may be detached. Cable or FFC disconnection. Motor driver failure. Main board failure. |
| 0x0019 | PRINTER | CR PID speed fall error. CR encoder failure. Motor driver failure. Main board failure. Tooth skip or improper tension of the timing belt. Paper jam. |
| 0x001B | PRINTER | CR PID excess load error. Main Board failure. Malfunction or crash of the firmware. |
| 0x001E | PRINTER | CR LOAD POSITION driving time error. CR encoder failure. Tooth skip or improper tension of the timing belt. Carriage overload. |
| 0x001F | PRINTER | CR LOAD POSITION excess load error. CR encoder failure. CR motor failure. Carriage overload. Tooth skip or improper tension of the timing belt. Cable or FFC disconnection. |
| 0x0020 | PRINTER | CR LOAD POSITION excess speed error. The CR motor rotates faster than expected during printing. CR encoder failure. Tooth skip or improper tension of the timing belt. Motor driver failure. Main board failure. |
| 0x0021 | PRINTER | CR LOAD POSITION reverse error. The CR motor does not rotate to the normal direction during printing. CR encoder failure. Paper jam. Tooth skip or improper tension of the timing belt. Main board failure. |
| 0x0028 | PRINTER | PF PID driving time error. Main board failure. |
| 0x0029 | PRINTER | PF PID excess load error. Encoder failure. PF motor failure. PF Mechanism overload. Cable or FFC disconnection. Tooth skip or improper tension of the timing belt. Cable or FFC disconnection. Motor driver failure. Main board failure. |
| 0x002A | PRINTER | PF PID excess speed error. Encoder failure. Tooth skip or improper tension of the timing belt. Motor driver failure. Main board failure. |
| 0x002B | PRINTER | PF PID reverse error. Encoder failure. Tooth skip or improper tension of the timing belt. Paper jam. Motor driver failure. Main board failure. |
| 0x002C | PRINTER | PF PID lock error. Encoder failure. PF motor failure. PF Mechanism overload. Cable or FFC disconnection. Motor driver failure. Main board failure. |
| 0x0032 | PRINTER | PF LOAD POSITION driving time error. Encoder failure. PF motor failure. PF Mechanism overload. Cable or FFC disconnection. Main board failure. |
| 0x0033 | PRINTER | PF LOAD POSITION excess load error. Encoder failure. PF motor failure. PF Mechanism overload. Cable or FFC disconnection. Tooth skip or improper tension of the timing belt. |
| 0x0034 | PRINTER | PF LOAD POSITION excess speed error. Encoder failure. Motor driver failure. Main board failure. Tooth skip or improper tension of the timing belt. Motor driver failure. Main board failure. |
| 0x0035 | PRINTER | PF LOAD POSITION reverse error. Encoder failure. Tooth skip or improper tension of the timing belt. Motor driver failure. Main board failure. |
| 0x003C | PRINTER | ASF (1st) PID driving time error. Firmware error. |
| 0x003D | PRINTER | ASF (1st) PID excess load error. The ASF (1st) motor stopped running in the middle of the operation. Paper jam. Mechanism overload. Broken gear. Encoder error. Contaminated encoder scale. Disconnected or broken FFC. Encoder sensor failure. Motor failure. Main board failure. |
| 0x003E | PRINTER | ASF (1st) PID excess speed error. Encoder error. Contaminated encoder scale. Disconnected or broken FFC. Encoder sensor failure. Motor driver failure. Main board failure. |
| 0x003F | PRINTER | ASF (1st) PID reverse error. Paper feed fails. Paper jam. Mechanism overload. Broken gear. Encoder error. Contaminated encoder scale. Disconnected or broken FFC. Encoder sensor failure. Main board failure. |
| 0x0040 | PRINTER | ASF (1st) PID lock error. The ASF (1st) motor did not run. Paper jam. Mechanism overload. Broken gear. Encoder error. Contaminated encoder scale. Disconnected or broken FFC. Encoder sensor failure. Motor failure. Main board failure. |
| 0x0042 | PRINTER | ASF (1st) PID torsion limit error. The ASF motor did broken or obstructed. Pickup roller drive mechanism overload. |
| 0x0043 | PRINTER | Head temperature error. Printhead failure. Main board failure. |
| 0x0046 | PRINTER | ASF (1st) load position driving time error. Firmware error. |
| 0x0047 | PRINTER | ASF (1st) load position excess load error. The ASF (1st) motor stopped running in the middle of the operation. Paper jam. Mechanism overload. Broken gear. Encoder error. Contaminated encoder scale. Encoder sensor failure. Motor failure. Main board failure. |
| 0x0048 | PRINTER | ASF (1st) load position excess speed error. Encoder error. Contaminated encoder scale. Disconnected or broken FFC. Encoder sensor failure. Motor driver failure. Main board failure. |
| 0x0049 | PRINTER | ASF (1st) load position reverse error. Paper feed fails. Paper jam. Mechanism overload. Broken gear. Encoder error. Contaminated encoder scale. Disconnected or broken FFC. Motor encoder failure. Main board failure. |
| 0x0050 | PRINTER | ASF (2nd) PID driving time error. Firmware error. |
| 0x0051 | PRINTER | ASF (2nd) PID excess load error. The ASF (2nd) motor stopped running in the middle of the operation. Paper jam. Mechanism overload. Broken gear. Encoder error. Contaminated encoder scale. Disconnected or broken FFC. Encoder sensor failure. Motor failure. Main board failure. |
| 0x0052 | PRINTER | ASF (2nd) PID excess speed error. Encoder error. Contaminated encoder scale. Disconnected or broken FFC. Encoder sensor failure. Motor driver failure. Main board failure. |
| 0x0053 | PRINTER | ASF (2nd) PID reverse error. Paper feed fails. Paper jam. Mechanism overload. Broken gear. Encoder error. Contaminated encoder scale. Disconnected or broken FFC. Encoder sensor failure. Main board failure. |
| 0x0054 | PRINTER | ASF (2nd) PID lock error. The ASF (2nd) motor did not run. Paper jam. Mechanism overload. Broken gear. Encoder error. Contaminated encoder scale. Disconnected or broken FFC. Encoder sensor failure. Motor failure. Main board failure. |
| 0x005A | PRINTER | ASF (2nd) load position driving time error. Firmware error. |
| 0x005B | PRINTER | ASF (2nd) load position excess load error. The ASF (2nd) motor stopped running in the middle of the operation. Paper jam. Mechanism overload. Broken gear. Encoder error. Contaminated encoder scale. Encoder sensor failure. Motor failure. Main board failure. |
| 0x005C | PRINTER | ASF (2nd) load position excess speed error. Encoder error. Contaminated encoder scale. Disconnected or broken FFC. Encoder sensor failure. Motor driver failure. Main board failure. |
| 0x005D | PRINTER | ASF (2nd) load position reverse error. Paper feed fails. Paper jam. Mechanism overload. Broken gear. Encoder error. Contaminated encoder scale. Disconnected or broken FFC. Motor encoder failure. Main board failure. |
| 0x0064 | PRINTER | I/S PID driving time error. Firmware error. |
| 0x0065 | PRINTER | I/S PID excess load error. The I/S motor stopped running in the middle of the operation. The ink system was stopped. Mechanism overload. Broken gear. Encoder error. Contaminated encoder scale. Motor failure. Main board failure. |
| 0x0066 | PRINTER | I/S PID excess speed error. Motor encoder failure. Contaminated encoder scale. Disconnected or broken FFC. Encoder sensor failure. Motor driver failure. Main board failure. |
| 0x0067 | PRINTER | I/S PID reverse error. Operation failure of the I/S motor. The ink system was stopped. Mechanism overload. Broken gear. Encoder error. Contaminated encoder scale. Disconnected or broken FFC. Encoder sensor failure. Main board failure. |
| 0x0068 | PRINTER | I/S PID lock error. The I/S motor did not run. The ink system was stopped. Mechanism overload. Broken gear. Encoder error. Contaminated encoder scale. Disconnected or broken FFC. Encoder sensor failure. Motor failure. Main board failure. |
| 0x006E | PRINTER | I/S LOAD POSITION driving time error. Firmware error. |
| 0x006F | PRINTER | I/S LOAD POSITION excess load error. The I/S motor stopped running in the middle of the operation. The ink system was stopped. Mechanism overload. Broken gear. Encoder error. Contaminated encoder scale. Motor failure. Main board failure. |
| 0x0070 | PRINTER | I/S LOAD POSITION excess speed error. Encoder error. Contaminated encoder scale. Disconnected or broken FFC. Encoder sensor failure. Motor driver failure. Main board failure. |
| 0x0071 | PRINTER | I/S LOAD POSITION reverse error. Operation failure of the I/S motor. The ink system was stopped. Mechanism overload. Broken gear. Encoder failure. Contaminated encoder scale. Disconnected or broken FFC. Encoder sensor failure. Main board failure. |
| 0x008C | PRINTER | STK PID driving time error. Malfunction or crash of the firmware. |
| 0x008D | PRINTER | STK PID excess load error. The Stacker motor stopped running in the middle of the operation. Overload of the mechanism. Broken gears. Encoder error. Contamination of the Stacker motor encoder scale. Failure of the Stacker motor. Failure of the main board. |
| 0x008E | PRINTER | STK PID excess speed error. Failed to read the Stacker motor encoder. Contamination of the Stacker motor encoder scale. Damaged FFC. Sensor failure. Failure of the Stacker motor. Failure of the main board. |
| 0x008F | PRINTER | STK PID reverse error. Operation failure of the stacker motor. Overload of the mechanism. Broken gears. Encoder failure. Contamination of the Stacker motor encoder scale. Damaged FFC. Failure of the Stacker motor encoder sensor. Failure of the main board. |
| 0x0090 | PRINTER | STK PID lock error. The Stacker motor did not run. Overload of the mechanism. Broken gears. Encoder failure. Contamination of the Stacker motor encoder scale. Damaged FFC. Failure of the Stacker motor encoder sensor. Failure of the Stacker motor. Failure of the main board. |
| 0x0096 | PRINTER | STK load position driving time error. Malfunction or crash of the firmware. |
| 0x0097 | PRINTER | STK load position excess load error. The Stacker motor stopped running in the middle of the operation. Overload of the mechanism. Broken gear. Encoder failure. Contamination of the Stacker motor encoder scale. Failure of the Stacker motor. Failure of the main board. |
| 0x0098 | PRINTER | STK load position excess speed error. Failed to read the Stacker motor encoder. Contamination of the Stacker motor encoder scale. Damaged FFC. Encoder sensor failure. Failure of the Stacker motor driver. Failure of the main board. |
| 0x0099 | PRINTER | STK load position reverse error. Operation failure of the Stacker motor. Overload of the mechanism. Broken gear. Encoder failure. Contamination of the Stacker motor encoder scale. Damaged FFC. Failure of the Stacker motor encoder sensor. Failure of the main board. |
| 0x00B4 | PRINTER | LIFT TWO PID driving time error. |
| 0x00B5 | PRINTER | LIFT TWO PID excess load error. |
| 0x00B6 | PRINTER | LIFT TWO PID excess speed error. |
| 0x00B8 | PRINTER | LIFT TWO PID Lock error. |
| 0x01E0 | PRINTER | APG/RLS PID excess driving time error. |
| 0x01E1 | PRINTER | APG/RLS PID excess load error. |
| 0x01E2 | PRINTER | APG/RLS PID excess speed error. |
| 0x01E3 | PRINTER | APG/RLS PID reverse error. |
| 0x01E4 | PRINTER | APG/RLS PID lock error. |
| 0x01EA | PRINTER | PG load position excess driving time error. |
| 0x01EB | PRINTER | PG load position excess load error. |
| 0x01EC | PRINTER | PG load position excess speed error. |
| 0x01ED | PRINTER | PG load position reverse error. |
| 0x01F4 | PRINTER | CAP PID excess driving time error. |
| 0x01F5 | PRINTER | CAP PID excess load error. |
| 0x01F6 | PRINTER | CAP PID excess speed error. |
| 0x01F7 | PRINTER | CAP PID reverse error. |
| 0x01F8 | PRINTER | CAP PID lock error. |
| 0x026C | PRINTER | MSF load position driving time error. |
| 0x026D | PRINTER | MSF load position excess load error. |
| 0x026E | PRINTER | MSF load position excess speed error. |
| 0x026F | PRINTER | MSF PID reverse error. |
| 0x0270 | PRINTER | MSF PID lock error. |
| 0x02A8 | PRINTER | RASF PID driving time error. Malfunction or crash of the firmware. |
| 0x02A9 | PRINTER | RASF PID excess load error. The RASF motor stopped running in the middle of the operation. Overload of the mechanism. Disengaging or breakage of the gears. Failed to read the RASF encoder. Contamination of the RASF encoder scale. Failure of the RASF motor (not completely broken). Failure of the main board. |
| 0x02AA | PRINTER | RASF PID excess speed error. Failed to read the RASF motor encoder. Contamination of the RASF encoder scale. Damage or skew of the RASF encoder FFC. Failure of the RASF encoder sensor Failure of the RASF motor driver. Failure of the main board. |
| 0x02AB | PRINTER | RASF PID reverse error. Operation failure of the RASF motor, stopped by obstacles. Overload of the mechanism. Disengaging or breakage of the gears. Failed to read the RASF encoder. Contamination of the RASF encoder scale. Damage or skew of the RASF motor cable/encoder FFC. Failure of the RASF encoder sensor. Failure of the main board. |
| 0x02AC | PRINTER | RASF PID lock error. The RASF motor did not run. Overload of the mechanism. Disengaging or breakage of the gears. Failed to read the RASF encoder. Contamination of the RASF encoder scale. Break, skew or damage of the RASF motor cable/encoder FFC. Failure of the RASF encoder sensor. Failure of the RASF motor (the lead wire is broken or the connector is disconnected). Failure of the main board. |
| 0x02B2 | PRINTER | RASF load position driving time error. Malfunction or crash of the firmware. |
| 0x02B3 | PRINTER | RASF load position excess load error. The RASF motor stopped running in the middle of the operation. Overload of the mechanism. Disengaging or breakage of the gears. Failed to read the RASF encoder. Contamination of the RASF encoder scale. Failure of the RASF motor (not completely broken). Failure of the main board. |
| 0x02B4 | PRINTER | RASF load position excess speed error. Failed to read the RASF encoder. Contamination of the RASF encoder scale. Damage or skew of the RASF encoder FFC. Failure of the RASF encoder sensor Failure of the RASF motor driver. Failure of the main board. |
| 0x02B5 | PRINTER | RASF load position reverse error. Operation failure of the RASF motor, stopped by obstacles. Overload of the mechanism. Disengaging or breakage of the gears. ailed to read the RASF encoder. Contamination of the RASF motor encoder scale. Damage or skew of the RASF motor cable/encoder FFC. Failure of the RASF encoder sensor. Failure of the main board. |
| 0x02BC | PRINTER | EJ2 PID driving time error. Malfunction or crash of the firmware. |
| 0x02BD | PRINTER | EJ2 PID excess load error. The EJ2 motor stopped running in the middle of the operation. The EJ2 was stopped by Obstacles such as jammed paper Overload of the paper feed mechanism Disengaging or breakage of the gears. Failed to read The EJ2 motor encoder. The timing belt become frayed or jumping. Contamination of The EJ2 encoder scale. Disconnection, break, skew or damage of The EJ2 motor cable/encoder FFC. Failure of The EJ2 motor (not completely broken). Failure of the main board. |
| 0x02BE | PRINTER | EJ2 PID excess speed error. Failed to read The EJ2 motor encoder. Contamination of The EJ2 encoder scale. Skew or damage of The EJ2 encoder FFC. Failure of The EJ2 encoder sensor Failure of The EJ2 motor driver. Failure of the main board. |
| 0x02BF | PRINTER | EJ2 PID reverse error. Paper feed fails, stopped by obstacles. Paper feed was stopped by Obstacles such as jammed paper Overload of the paper feed mechanism Disengaging or tooth breakage of wheel train of the paper feed mechanism Failed to read The EJ2 motor encoder. Jumping of The EJ2 timing belt. Contamination of The EJ2 encoder scale. Skew or damage of The EJ2 encoder FFC. Failure of The EJ2 encoder sensor. Failure of the main board. |
| 0x02C0 | PRINTER | EJ2 PID lock error. The EJ2 motor did not run or obstacles exist in the paper path. Overload of the paper feed mechanism. The EJ2 timing belt become frayed, jumping, or the wheel train of paper feed mechanism is disengaged or its tooth is broken Failed to read The EJ2 motor encoder. Contamination of The EJ2 encoder scale. Disconnection, break, skew or damage of The EJ2 encoder FFC. Failure of The EJ2 encoder sensor. Failure of The EJ2 motor (the lead wire is broken or the connector is disconnected). Failure of the main board. |
| 0x02C6 | PRINTER | EJ2 load position driving time error. Malfunction or crash of the firmware. |
| 0x02C7 | PRINTER | EJ2 load position excess load error. The EJ2 motor stopped running in the middle of the operation. The EJ2 was stopped by Obstacles such as jammed paper Overload of the paper feed mechanism Disengaging or breakage of the gears. Failed to read The EJ2 motor encoder. Jumping of the timing belt. Contamination of The EJ2 encoder scale. Failure of The EJ2 motor (not completely broken). Failure of the main board. |
| 0x02C8 | PRINTER | EJ2 load position excess speed error. Failed to read The EJ2 motor encoder. Contamination of The EJ2 encoder scale. Skew or damage of The EJ2 encoder FFC. Failure of The EJ2 encoder sensor Failure of The EJ2 motor driver. Failure of the main board. |
| 0x02C9 | PRINTER | EJ2 load position reverse error. Paper feed fails, stopped by obstacles. Paper feed was stopped by Obstacles such as jammed paper Overload of the paper feed mechanism Disengaging or tooth breakage of wheel train of the paper feed mechanism Failed to read The EJ2 motor encoder. Jumping of The EJ2 timing belt. Contamination of The EJ2 encoder scale. Skew or damage of The EJ2 encoder FFC. Failure of The EJ2 encoder sensor. Failure of the main board. |
| 0x02D0 | PRINTER | Roll PID excess driving time error. Main Board failure. Malfunction or crash of the firmware. |
| 0x02D1 | PRINTER | Roll PID excess load error. The roll motor stopped running in the middle of the operation. |
| 0x02D2 | PRINTER | Roll PID excess speed error. Damage or dropout of the roll unit drive train gears. |
| 0x02D3 | PRINTER | Roll PID reverse error. The roll motor stopped running in the middle of the operation. |
| 0x02D4 | PRINTER | Roll PID lock error. The roll motor stopped running in the middle of the operation. |
| 0x03F4 | PRINTER | DCP driving time error. Malfunction or crash of the firmware Failure of the DCP Motor. |
| 0x7531 | PRINTER | PE sensor wrong light emission amount error. PE Sensor failure. Main board failure. |
| 0x7532 | PRINTER | PW sensor failure. Main board failure. |
| 0x7533 | PRINTER | PE sensor failure. Main board failure. |
| 0x7534 | PRINTER | Emergency stop error due to opened cover. The cover sensor may be broken. |
| 0x7535 | PRINTER | Abnormal temperature of internal power supply unit. Damage of the power cable. Failure of the power supply unit. Main Board Failure. |
| 0x7536 | PRINTER | Abnormal temperature of internal power supply unit. Foreign object. Failure of the power supply unit. Main Board Failure. |
| 0x7537 | PRINTER | PW detector error. Cannot set the value of the threshold level for paper. |
| 0x7919 | PRINTER | Printer head failure. X-Hot detection error before printing. Head thermistor detects abnormal temperature. Main board failure. |
| 0x791A | PRINTER | Printer head failure. X-Hot detection error during flushing. Head thermistor detects abnormal temperature. Main board failure. |
| 0x791B | PRINTER | Printer head failure. Transistor abnormal temperature error. Head thermistor detects abnormal temperature. Main board failure. |
| 0x791C | PRINTER | Printer head failure. Head abnormal temperature error. Main board failure. |
| 0x791D | PRINTER | Printer head failure. Head abnormal temperature error. Main board failure. |
| 0x791E | PRINTER | Circuit error or blowout of a fuse. Main board failure. |
| 0x791F | PRINTER | Cannot drop the voltage to temporarily avoid abnormal printing. |
| 0x7920 | PRINTER | VBS overvoltage error. Head FFC failure. Failure of the head. Main Board Failure. |
| 0x7921 | PRINTER | Head FFC abnormal voltage error. Head FFC failure. Failure of the head. Failure of the main board. |
| 0x7923 | PRINTER | HCS error. Failure of the print head. Damage of the head FFC. Main Board Failure. |
| 0x7D02 | PRINTER | Additional cassette error. Connection of option cassette is not correct. |
| 0x7D33 | PRINTER | Additional cassette error. Connection of option cassette is not correct. |
| 0x7D34 | PRINTER | Additional cassette error. Connection of option cassette is not correct. |
| 0x7D65 | PRINTER | Additional recovery mode error. Malfunction or crash of the firmware. |
| 0x7D97 | PRINTER | Additional cassette error. Failure of the connector part of option cassette. Failure of the main baord of the option cassette. Failure of the main board. |
| 0x7D98 | PRINTER | Additional cassette error. Failure of the connector part of option cassette. Failure of the main baord of the option cassette. Failure of the main board. |
| 0x7D99 | PRINTER | Additional cassette error. Failure of the connector part of option cassette. Failure of the main baord of the option cassette. Failure of the main board. |
| 0x7D9A | PRINTER | Additional cassette error. Failure of the connector part of option cassette. Failure of the main baord of the option cassette. Failure of the main board. |
| 0x7D9B | PRINTER | Additional cassette error. Failure of the connector part of option cassette. Failure of the main baord of the option cassette. Failure of the main board. |
| 0x7D9C | PRINTER | Additional cassette error. Failure of the connector part of option cassette. Failure of the main baord of the option cassette. Failure of the main board. |
| 0x7D.. | PRINTER | Additional cassette error. Failure of the connector part of option cassette. Failure of the main baord of the option cassette. Failure of the main board. |
| 0x7D9E | PRINTER | Additional cassette error. Failure of the connector part of option cassette. Failure of the main baord of the option cassette. Failure of the main board. |
| 0x7D9F | PRINTER | Additional cassette error. Failure of the connector part of option cassette. Failure of the main baord of the option cassette. Failure of the main board. |
| 0x7DA0 | PRINTER | Additional cassette error. Failure of the connector part of option cassette. Failure of the main baord of the option cassette. Failure of the main board. |
| 0x7DA1 | PRINTER | Additional cassette error. Failure of the connector part of option cassette. Failure of the main baord of the option cassette. Failure of the main board. |
| 0x7DA2 | PRINTER | Additional cassette error. Failure of the connector part of option cassette. Failure of the main baord of the option cassette. Failure of the main board. |
| 0x80E9 | PRINTER | Blowout of a fuse (CRCM). |
| 0x80EA | PRINTER | ASIC access error. The data stored on the PCD is incorrect or corrupted. |
| 0x80EB | PRINTER | General ink device error. Error in the printer settings. Main Board Failure. |
| 0x80EC | PRINTER | General ink device error. Error in the printer settings. Main Board Failure. |
| 0x80ED | PRINTER | General ink device error. Error in the printer settings. Main Board Failure. |
| 0x80EE | PRINTER | CRCM access error. |
| 0x80EF | PRINTER | CRCM access error. |
| 0x80F0 | PRINTER | CRCM access error. |
| 0x80F2 | PRINTER | CSIC access error. Disconnected or broken FFC. Failure of the CSIC terminal/CR contact module. Main board failure. |
| 0x82.. | PRINTER | ILS environmental error. The PIS sensor received unexpected amount of light. |
| 0x82DE | PRINTER | ILS continuous reflected light error. The PIS sensor received unexpected amount of reflected light from the jig I/C. Anti-reflection film of the I/C has been removed. |
| 0x82DF | PRINTER | ILS no reflected light error. Electric voltage for the PIS sensor is insufficient. Failure of the main board. The PIS sensor has deteriorated. Reflected light from the I/C is insufficient. |
| 0x82E0 | PRINTER | ILS shift length error. Positioning of the I/C and the PIS sensor is inaccurate. |
| 0x82E1 | PRINTER | ILS empty JIG error. Light from empty jig I/C is insufficient. |
| 0x82E2 | PRINTER | Excessive Light error. Light from full jig I/C is too much. |
| 0x82E3 | PRINTER | Insufficient Light error. Electric voltage for the PIS sensor is insufficient. Break of the FFC. The PIS sensor has deteriorated. Reflected light from the I/C is insufficient. |
| 0x84D1 | PRINTER | Home position seeking error. Foreign object. Deformation. Change lever failure. Paper jam. |
| 0x84D2 | PRINTER | CR lock release error. The carriage does not move from the CR lock position. |
| 0x84D3 | PRINTER | Contact detection error. CR Encoder failure. |
| 0x84D4 | PRINTER | Paper jam error. Foreign object. Deformation. Change lever failure. Paper jam. |
| 0x84DA | PRINTER | PF runaway error. Encoder failure. Motor driver failure. Main board failure. |
| 0x84DB | PRINTER | APG target position acquisition error. APG motor failure. APG sensor failure. Main board failure. |
| 0x84E3 | PRINTER | APG error. Failed to move PG swiching structure when CR push in gear of PG swiching structure. CR cannot push in gear due to having a bad bite. Failure of PG swiching structure. |
| 0x8611 | PRINTER | Release home position error. RLS home position is not detected even if RLS is reset. |
| 0x86C4 | PRINTER | Ink cartridge replacement timing contact detection error. Cartridge comes in contact with the housing because it is not securely installed. |
| 0x86C5 | PRINTER | Wiping contact error. Carriage overload error. Deformation of the main frame. Deformation of the CR guide rail. CR Encoder failure. CR Motor failure. Cable disconnection. |
| 0x86C6 | PRINTER | Valve initialization contact point detection error. Carriage overload. Ink system failure. Main board failure. |
| 0x86C7 | PRINTER | I/S clutch operation contact point detection error. Ink system failure. Main board failure. |
| 0x8819 | PRINTER | Ink leak error. Erroneously detected by dew condensation ink leak. |
| 0xEA61 | PRINTER | Factor other than printer device error. Scanner or ADF failure. |
| 0xEA62 | PRINTER | Driver mismatch error. An unsupported driver is used. |
| 0xEA63 | PRINTER | PCD verify error. |
| 0x00 | SCANNER | Fatal error does not occur. |
| 0x01 | SCANNER | Scanner/ADF PID excess speed error. Encoder failure. Motor driver failure. Main board failure. |
| 0x02 | SCANNER | Scanner/ADF PID reverse error. Encoder failure. Paper jam. |
| 0x03 | SCANNER | Scanner/ADF PID lock error. Encoder failure. Motor failure. Mechanism overload. Cable or FFC disconnection. |
| 0x04 | SCANNER | Scanner/ADF PID acceleration lock error. Encoder failure. Motor failure. Paper jam. Cable or FFC disconnection. |
| 0x05 | SCANNER | Scanner/ADF PID excess load. Encoder failure. Motor failure. Mechanism overload. Cable or FFC disconnection. |
| 0x06 | SCANNER | Scanner/ADF PID driving time error. Main board failure. |
| 0x09 | SCANNER | Scanner/ADF BS+ excess speed error. Encoder failure. Motor driver failure. Main board failure. |
| 0x0A | SCANNER | Scanner/ADF BS+ reverse error. Encoder failure. Paper jam. |
| 0x0B | SCANNER | Scanner/ADF BS+ lock error. Encoder failure. Motor failure. Mechanism overload. Paper jam. Cable or FFC disconnection. |
| 0x0D | SCANNER | Scanner/ADF BS+ excess load error. Encoder failure. Motor failure. Mechanism overload. Paper jam. Cable or FFC disconnection. |
| 0x0E | SCANNER | Scanner/ADF BS+ driving time error. Encoder failure. Motor failure. Mechanism overload. Paper jam. Cable or FFC disconnection. |
| 0x10 | SCANNER | Scanner/ADF home position detection error. CIS Module failure. Upper housing failure. Lower housing failure. Scanner motor failure. Insufficient grease. Foreign object. Cable disconnection. Main board failure. |
| 0x11 | SCANNER | Scanner/ADF contact detection distance exceeded error. CIS Module failure. Scanner Housing failure. Cable or FFC disconnection. Motor failure. Main board failure. |
| 0x12 | SCANNER | Scanner/ADF opposite side contact detection distance exceeded error. CIS Module failure. Scanner Housing failure. Main board failure. Cable or FFC disconnection. Motor failure. Main board failure. |
| 0x13 | SCANNER | Scanner/ADF opposite side wrong contact detection distance error. CIS Module failure. Scanner Housing failure. Main board failure. Cable or FFC disconnection. Motor failure. |
| 0x14 | SCANNER | Scanner/ADF measurement error. Drive mechanism is overloaded. Insufficient grease. Foreign object. Lack of gears. Deformation. |
| 0x20 | SCANNER | Scanner/ADF LED light error. CIS Module failure. Foreign object. Scanner housing upper failure (home seek pattern is dirty). Main board failure. |
| 0x21 | SCANNER | Scanner/ADF ALD PID excess speed error. ALD motor failure. Motor driver failure. Cable or FFC disconnection. |
| 0x22 | SCANNER | Scanner/ADF ALD PID reverse error. ALD motor failure. Motor driver failure. Cable or FFC disconnection. |
| 0x23 | SCANNER | Scanner/ADF ALD PID lock error. ALD motor failure. Motor driver failure. Cable or FFC disconnection. |
| 0x24 | SCANNER | Scanner/ADF ALD PID acceleration lock. ALD motor failure. Motor driver failure. Cable or FFC disconnection. |
| 0x25 | SCANNER | Scanner/ADF ALD PID excess load error. ALD motor failure. Motor driver failure. Cable or FFC disconnection. |
| 0x26 | SCANNER | Scanner/ADF ALD PID driving time error. ALD motor failure. Motor driver failure. Cable or FFC disconnection. |
| 0x30 | SCANNER | Scanner/ADF option error. Cable or FFC disconnection. Main board failure. |
| 0x31 | SCANNER | Scanner/ADF MAIN-A Supply circuit error. Main board failure. Connection error between the Main board and Scanner Main Board. Scanner main board failure. |
| 0x36 | SCANNER | Scanner/ADF paper jam error. Paper jam. Foreign object. Loading or ejecting paper out of the standard range. Using long paper. |
| 0x41 | SCANNER | Scanner/ADF FB PID excess speed error. Encoder failure. Tooth skip or improper tension of the timing belt. Motor driver failure. Main board failure. |
| 0x42 | SCANNER | Scanner/ADF FB PID reverse error. Encoder failure. Tooth skip or improper tension of the timing belt. Gear crack. Cable or FFC disconnection. Motor driver failure. Main board failure. |
| 0x43 | SCANNER | Scanner/ADF FB PID lock error. Encoder failure. Tooth skip or improper tension of the timing belt. Gear crack. Cable or FFC disconnection. Motor driver failure. Main board failure. |
| 0x44 | SCANNER | Scanner/ADF FB PID acceleration lock error. Encoder failure. Tooth skip or improper tension of the timing belt. Gear crack. Cable or FFC disconnection. Motor driver failure. Main board failure. |
| 0x45 | SCANNER | Scanner/ADF FB PID excess load error. Encoder failure. Tooth skip or improper tension of the timing belt. Gear crack. Cable or FFC disconnection. Motor driver failure. Main board failure. |
| 0x46 | SCANNER | Scanner/ADF FB PID driving time error. Main board failure. |
| 0x49 | SCANNER | Scanner/ADF FB BS+ excess speed error. Encoder failure. Gear crack. Cable or FFC disconnection. Motor driver failure. Main board failure. |
| 0x4A | SCANNER | Scanner/ADF FB BS+ reverse error. Encoder failure. Gear crack. Cable or FFC disconnection. Motor driver failure. Main board failure. |
| 0x4B | SCANNER | Scanner/ADF FB BS+ lock error. Encoder failure. Tooth skip or improper tension of the timing belt. Gear crack. Cable or FFC disconnection. Motor driver failure. Main board failure. |
| 0x4D | SCANNER | Scanner/ADF FB BS+ excess load error. Encoder failure. Tooth skip or improper tension of the timing belt. Gear crack. Cable or FFC disconnection. Motor driver failure. Main board failure. |
| 0x4E | SCANNER | Scanner/ADF FB BS+ driving time error. Main board failure. |
| 0x51 | SCANNER | Scanner/ADF automatic judgement error. |
| 0x52 | SCANNER | Scanner/ADF automatic judgement error. |
| 0x53 | SCANNER | Scanner/ADF automatic judgement error. |
| 0x54 | SCANNER | Scanner/ADF automatic judgement error. |
| 0x55 | SCANNER | Scanner/ADF automatic judgement error. |
반응형
